HL-20 CREW RESCUE VEHICLE

Slide 53 of 99

Notes:

The “luxury” crew rescue vehicle option was the Langley Research Center's $2-billion HL-20. Loosely based on a Soviet spaceplane design, it could carry a crew of eight and might even double as a "Personnel Launch System" mini-shuttle if launched on a Titan IV rocket. Its lifting body design would have provided superior maneuvrability for safe return from orbit. However, Congress balked at the price and cancelled all funding in 1990.

HL-20 carried by Lockheed's VENTURESTAR reusable launch vehicle.

SPACE STATION UPMASS/DOWNMASS:		NASA Space Shuttle (=STS)		OSC HL-20 "space taxi"
	Upmass (kg)	Return cargo (kg)	Waste (kg)	Return cargo (kg)	Difference (kg)
Frozen food + racks	2400	500	250		-500
Ambient food + racks	1150	300	300		-300
Clothes + stowage	2400	1450	950		-1450
Crew miscellaneous	1350	150	1150	75	-75
Crew health care	500	400	200	225	-175
Pressurized maintenance logistics	4550	3900	650		-3900
Pressurized scientific utilization	13800	12250	1550	7350	-4900
Unpressurized scientific utilization	3800	3150	650	1890	-1260
Unpressurized EVA equipment	1100	1100		1100	0
Unpressurized maintenance logistics	6650	4300	2350		-4300
Crew rotation gear	3650	3650		3650	0
TOTAL:	41350kg/year (both vehicles)	31150kg STS return	(8050kg STS return)	14290kg HL-20 return	-16860kg
