Slide 87 of 99
Notes:
When the International Space Station (ISS) was redesigned again in 1993, NASA & the Italian
Space Agency decided to expand the original Mini-Pressurized Logistics Module design. The new
MultiPurpose Logistics Module is twice as long and an carry up to 9000kg of cargo to ISS. The
European Space Agency also became a partner, since Alenia Spazio would use the same pressurized
module and some thermal subsystems in the Columbus Orbiting Facility as well. In return, ESA
provided three environmental control & life-support system units for use in the Multipurpose
Logistics Module.
Inside the MPLM. The module carries up to sixteen refrigerator-sized (203 x 105cm)
payload racks, five of which may contain refrigerators/freezers. Other so-called "Express Racks"
(visible on top of the picture) can be outfitted with lockers for small experiments. Additional
cargo can be carried in center aisle stowage containers.
Italy delivered the first “Leonardo” Multi-Purpose Logistics Module to NASA in July 1998. Two more
module -- “Rafaelo” and “Donatello” -- will also be delivered under the $300-million contract.
Italian astronauts will receive greater use of the Station as well as crew training for two
more ASI astronauts in return for the MPLM.
[
]
MPLM PAYLOAD RACK MASS SUMMARY |
|
|
|
|
|
RACK TYPE |
RACK WEIGHT (kg) |
MAX CARGO (kg) |
TOTAL WEIGHT (kg) |
CARGO TYPE |
|
International Standard Payload Rack (ISPRs) |
95 |
454 |
549 |
Users |
|
Refrigerator/Freezer Rack |
322 |
238 |
560 |
Crew (Users) |
|
Aisle Stowage Container (187 x 66 x ?? cm, ~0.58m3 volume) |
16.8 |
126.8 |
143.6 |
Crew |
|
Integrated Crew Resupply Rack (1.019m3volume, 454kg max.) |
109 |
296 |
405 |
Crew |
|
Passive Dry Cargo Resupply/Return Rack |
260 |
308 |
568 |
Spares,Users |
|
90-Day Clothing Soft Pack |
16.75 |
126.75 |
143.5 |
Crew (1 pack/crewmember) |
|
