Slide 13 of 99
Notes:
TRW won the $205-million OMV phase B contract in June 1986. Shown here is the “short range vehicle” that would be left behind in orbit between missions.
The TRW Orbital Maneuvering Vehicle would use a separate propellant / propulsion module that would be returned to Earth for refueling by the Shuttle. Two such modules are depicted here.
The TRW Orbital Transfer Vehicle could also be equipped with enlarged propellant tanks for demanding missions.
