In late 1966, the vertical launch & landing SSTO proponents at Douglas Aircraft Co. carried out
a study to determine whether ballistic VTVLs might be cost-competitive vs. winged VTHL TSTO
vehicles in the small payload class. Previous NASA & USAF studies had generally assumed ballistic single-stage vehicles might make sense for unmanned heavy-lift payloads but winged TSTOs were invariably chosen for small manned near-term missions. Consequently, Douglas had to define a small VTVL SSTO manned "space taxi" to demonstrate the key elements of the concept (aerospike engine, lightweight structures, ballistic reentry, vertical landing, actively cooled heatshield etc.) The resulting vehicle became known as "Saturn Application Single Stage to Orbit". Notable design features included an aft-mounted liquid oxygen tank to reduce the difference between vehicle center of gravity & center of aerodynamic pressure, and a hydrogen cooling system for the main engine to provide thermal protection during reentry. Thermal analysis indicated that although the engine itself would be adequately protected by this system, the areas located above the exhaust nozzles would not. Consequently, the designers had to resort to an ablative, expendable material (200 kilograms of Armstrong Insulcork 2760) bonded to the aluminium structure although it would increase the maintenance cost. The oxygen/hydrogen mixture ratio was 6:1 rather than 7:1 since the designers felt a high oxygen ratio would degrade the exhaust velocity & payload capability. 50% hydrogen slush was used to reduce the volume of the fuel tank. The 36-segment plug nozzle propulsion system would have operated at a pressure of 1500psia. It would be used for ascent, orbit insertion, de-orbit and (beginning at an altitude of 760 meters-) the final landing burn. The vehicle would carry enough propellant for hovering for 10 seconds before landing at an unprepared site, if necessary. The estimated landing accuracy of 1853 * 3700 m was not regarded as a major concern since the Gemini 6-12 flights achieved an average touchdown dispersion of only 6.85km although the capsule had essentially no maneuvering capability below 30.5km altitude. The reentry crossrange capability was about +-370km, permitting a safe landing at El Paso, TX or Wendover Range, UT after 2-3 orbits from Cape Canaveral. Wendover was the preferred emergency landing site since SASSTO easily could have been returned from nearby Hill AFB to Cape Canaveral in a "Pregnant Guppy" S-IV-B transport aircraft.
SASSTO had a payload capability of 3,629kg to a 185km orbit and the standard payload would be a
2-man Gemini spacecraft protected by a jettisonable fairing to reduce drag losses during ascent.
This would provide a safe emergency escape system for the test pilots, and the Gemini ejection seats, heatshield, paratchutes etc. (1542kg in all) could later be removed as the flight test program increases confidence in SASSTO reliability. Douglas envisioned this vehicle as a "space fighter" capable of satellite inspection missions, or space station resupply flights lasting a maximum of 48 hours. It could also deliver 2,812kg of liquid hydrogen to a spacecraft in Earth orbit.
Since SASSTO was loosely based on the Saturn S-IV-B rocket stage, Douglas also proposed an expendable version for use as a more capable upper stage with the Saturn IB and Saturn V launch vehicles.
The expendable SASSTO stage would have had a burnout mass of 7,400kg and carried 85,729kg of oxygen+hydrogen propellant. The stage was thus of a much more lightweight construction than the standard S-IV-B (12,949kg + 104,326kg LOX,LH2) and the new aerospike engine would have been more efficient as well (464s specific impulse vs. 426s for the J-2 engine). Consequently, the Saturn V's payload capability would have been boosted by 8-11t as well. The Saturn IB's basic 15876-kilogram payload capability to a 185km orbit would have increased to 23814-25855kg depending on whether SASSTO would be flown in expendable or reusable mode. The latter version was known as SARRA (Saturn Application Retrieval and Rescue Apparatus) and was intended for returning stranded Apollo crews from the lunar surface.
Finally, the Douglas design team also compared the cost of SASSTO with two different all-rocket VTHL TSTOs: a winged 1st stage plus lifting-body 2nd stage (center) and winged first & second stages (right).
All three vehicles were designed for a 2,812-kilogram payload although the lifting-body TSTO only was able to carry 2,086kg due to center of gravity problems. No attempt was made to estimate the marginal launch cost since there were too many unknown factors. VTVL SSTO would however be expected to yield a significant operational advantage since only a single vehicle must be maintained and the VTVL SSTO does not require a landing runway. SASSTO was expected to cost $1.1. billion to develop (=$5.88B at 1999 rates). The winged VTHL TSTO would cost 2.2 times as much to develop as SASSTO while the smaller lifting-body TSTO variant would be 50% more expensive. The winged and lifting-body 1st unit production costs would be 4 and 2.7 times higher than the SASSTO 1st unit cost, respectively. The general conclusion was that the complex winged or lifting-body TSTO shapes result in added liftoff and manufactured weights of a more expensive construction than ballistic wingless SSTOs. For example, the lifting-body TSTO dry mass (12,274kg + 2,086kg payload) is 2.4 times higher, and the winged TSTO weighs 3.6 times as much (18,176kg+2,812kg P/L) as SASSTO at touchdown. The gross liftoff weights bear the relationships of 1.0 (SASSTO; 97,887kg GLOW), 1.25 (lifting body orbiter TSTO; 122,245kg GLOW) and 1.91 (wing-body orbiter TSTO; 187,020kg GLOW). In that case, is the combination of lower reentry g-loads, better maneuvrability (landing go-around with jet engines) and improved crossrange really worth the cost of carrying wings...? Although TSTO thus appears to be uncompetitive vs. ballistic single-stage RLVs for small payloads, the authors admit that requirements for higher payloads (22.68-45.6t) may yield rapid increases in propellant mass fraction for winged two-stage vehicles, making TSTO more performance/cost-effective.
Liftoff Thrust: 1,232.655KN. Total Mass: 97,976kg. Total Length: 18.8m.
Payload capability: 3,674kg to a 185km low Earth orbit.
Stage Number 1: SASSTO. 36 x plug-nozzle engines (1500psia pressure, 1:6 mixture ratio). Gross Mass: 97,976kg. Empty Mass (core vehicle only): 6,668kg. Thrust: 1,232.65-1,557.5KN. Isp=367-464s. Length:18.8m. Width: 6.6m. Propellants: LOX/slush LH2.
"Enigma of Booster Recovery - Ballistic or Winged?” -- Bono,Senator & Garcia, SAE Conference Proceedings 1967/0382/ p.57
